Description
TENMARS LC-90 LAN Cable Tester Application
- Test Pin Configuration for 10/100 Base-T Cable
- 10 Base-2 cable, RJ45/RJ11 modular cables
- Verify cable continuity, open, short and miss wired
- Auto and Manual Scan
- Ground Wire Test
TENMARS LC-90 Specification
|
Display |
LED |
|
Connectors |
RJ-45 (8P8C) input/output |
|
Power |
9V 006P battery |
|
Cable types |
Unshielded twisted pair (UTP100,cat3,4 &5) Foil-screened twisted pair (FTP100 and 120, cat3,4 &5) Shielded twisted pair (STP150 IBM type 1&6) |
|
Remote terminators |
Sequence number*1 |
|
Function keys |
ON-OFF, TEST, AUTO, LOCK, MANU, BATT |
|
Dimension |
130 x 56 x 38mm (LxWxH) |
|
Weight |
About 150g |
|
Recognize wiring schemes |
EIA /TIA-568A/B,USOC,10 (100) Base/HUB,BNC/10 Base-2, 10 (100) Base-T, token ring |
|
Accessories |
User’s manual Carrying case x1 pc 9V battery x1 pc One patch cable (RJ-45 to RJ-45) |
