    Maximise efficiency in high-voltage environments with the UNI-T UT219PV Professional AC/DC Clamp Meter. Ideal for the photovoltaic industry, this instrument measures with astounding precision, offering AC/DC voltage and current measurements, resistance, capacitance, and temperature. Its ultra-thin 35mm jaw design fits easily into tight spaces, and an expandable current measurement range with the optional UT-CS09D sensor makes it incredibly versatile. Stay connected with the Bluetooth app, ensuring your data is always within reach. Rated CAT III 1500V/CAT IV 600V for safety, certified CE, RoHS, and cETLus, the UT219PV brings accuracy and durability to every task. Sensor sold separately.

    PDF download UNI-T UT219PV Datasheet

    Category: Tag:

    Enhance Your Solar Installation with the UNI-T UT219PV Professional AC/DC Clamp Meter

    The UNI-T UT219PV Professional AC/DC Clamp Meter is the ultimate tool for professionals in the high-voltage photovoltaic industry. Precision-engineered for reliability and accuracy, the UT219PV is a must-have for any solar installation professional. Experience seamless functionality with measurements of AC/DC voltage and current, resistance, and more—all delivered through a user-friendly interface with an automatic backlight and power-off features.

    UT219PV Professional AC/DC Clamp Meter - in use

    Unmatched Accuracy For Advanced Applications

    Gain a competitive edge with the UNI-T UT219PV’s capability to measure:

    • AC/DC Voltage up to 1500V/2500V
    • AC/DC Current up to 1000A
    • DC Power calculations up to 2500KVA

    Designed With The User In Mind

    • Ergonomic Design: The 35mm ultra-thin jaw is perfect for narrow spaces in combiner boxes or inverters, ensuring ease of use even in tight spaces.
    • External Clamp Sensor Support: Expand your AC current measurement up to 3000A with the UT-CS09D flex clamp sensor. (UT-CS09D flex clamp is not included with the UNI-T UT219PV model)
    • Safety At The Forefront: Enjoy peace of mind with the CAT III 1500V/CAT IV 600V safety rating and robust IP65 protection against dust and water.

    UT219PV Professional AC/DC Clamp Meter - in use

    Smart Features For Efficient Workflows

    • Bluetooth Connectivity: Pair the UT219PV with the dedicated Bluetooth app to capture, record, and share your measurement data effortlessly.
    • Intuitive Polarity Indication: Avoid errors with automatic visual and audible alerts if the voltage falls below -10V DC, ensuring correct readings every time.

    UT219PV Professional AC/DC Clamp Meter-in use

    Trusted Quality and Compliance

    • Certifications: The UT219PV has internationally recognised certifications such as CE, RoHS, and cETLus, upholding the highest standards of quality.

    Designed to streamline your workflow and provide the accuracy needed for solar panel installation and maintenance, the UT219PV is an essential instrument for the modern electrician. Add the UT219PV Professional AC/DC Clamp Meter to your toolkit today and power up your productivity!

    External clamp sensor: The UT-CS09D flex clamp sensor is supported, which means the AC current measurement range can expand to 3000A, and the flexible coils can handle measurements in narrow spaces.
    UT219PV Professional AC/DC Clamp Meter - in use
    Please note that specifications may be subject to change without notice and that the product is shipped without the UT-CS09D flex clamp sensor, which is available for purchase separately.

    Weight 1 kg

    Specifications

    Technical Specifications

    Current (ACA)

    999.9A

    40Hz~100Hz:±(2.0%+5)

    100Hz~1000Hz:±(2.5%+5)

    Current (DCA)

    999.9A

    ±(2.0%+5)

    Voltage (ACV)

    999.9V/1500V

    40Hz~1000Hz: ±(1.0%+5)

    Voltage (DCV)

    999.9V/2500V

    ±(1.0%+5)

    Voltage (DC mV)

    999.9mV

    ±(1.0%+5)

    ACV (with LPF)

    999.9V

    ±(2.0%+9)

    ACA (with LPF)

    999.9A

    ±(2.5%+9)

    ACA (with LPF): flex clamp sensor

    30.00A/300.0A/3000A

    ±(4.0%+9) (center area)

    ACA: with flex clamp sensor

    30.00A/300.0A/3000A

    ±(3.0%+5) (center area)

    Power (DC)

    999.9 kVA/2500 kVA

    ±(2.0%+20)

    Frequency (A&V)

    5.0 Hz to 999.9Hz

    ±(0.5%+5)

    Resistance (Ω)

    999.9Ω/9.999KΩ/99.99kΩ

    ±(1.0%+5)

    Capacitance (F)

    100.0μF/1000μF

    ±(1.0%+5)

    Temperature

    -40°C~400°C/-40°F~752°F

    ±(1.0%+30); ±(1.0%+60)

    Power supply

    AAA x 1

    Product dimension

    197 x 34.5 x 39.9mm

    Product color

    Grey + Red

    Accessories

    Test probe, temperature probe, batteries, manual
