REED K4020 Portable Stroboscope

AUD $479.00 .( AUD $526.90 inc. GST )


For all your equipment calibration needs, visit our MyCalibration website.


Free Delivery on orders over $1000
Shipping time may vary for certain products*

Product Enquiry

If you would like more information regarding this product, simply email us here.

  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    mm_logo_04

    Reed K4020 has a stroboscopic flash rate of 100 to 10000 flashes per minute (FPM) and it’s able to direct reading of RPMs. Inspecting and measuring the speed of moving parts is quick and accurate using this portable digital stroboscope. Reed K4020 it’s an ideal instrument for inspecting and measuring the speed of moving gears, fans, centrifuges, etc.

    Authorised Australian Distributor.



    SKU: REED K4020 Categories: , Tag:

    The K4020 is a competitively priced REED Portable Stroboscope which comes complete with useful options as standard. The K4020 Handheld Stroboscope also has a “freeze the motion” function and measures the motion without any contact. The REED K4020 Handheld Stroboscope maximises the use of one-chip micro-computer LSI circuit and crystal control time-base and assures a good accuracy of ±1% and 1 fpm/rpm resolution.

    REED K4020 Features

    • microprocessor circuit design
    • high accuracy
    • digital readout
    • light duty
    • ideal for inspecting and measuring the speed of moving gears, fans, centrifuges, pumps, motors and other equipment.

    REED K4020 Specifications

    • Flash Range: 100 to 100,000 fpm (flashes per minute)
    • Resolution: 1 rpm/fpm
    • Accuracy: º1%: 100 to 5000 fpm; º0.05%: >= 5000 fpm
    • Sampling Rate: 1/second
    • Calibration: Crystal time base and microprocessor circuit, does not necessarily take any external calibration procedure
    • Power Supply: 230 VAC, 50/60 Hz
    • Dimensions: 210 x 120 x 120mm
    • Weight: 1kg



    Weight 2 kg

    How to Use

    Checking Speed
    Power on your Portable Stroboscope by switching the power switch to on the “ON” position. Determine the range switch to “Low” or “High” position. Start checking the speed and always be sure that the strobe is flashing in unison (one to one) with the object being monitored. Turn the dial until two images appear – this will double the actual speed. Then lower the flashing rate until a single and stationary image appears – this is the actual true speed.

    Checking Motion
    With this Reed Portable Stroboscope you can easily made motion analysis. Simply locate the actual speed as mentioned above and then turn the dial slowly up or down. This will give a slow motion effect allowing complete speed inspection.
