Discover precision and versatility with the Fluke i2000 Flex AC Current Clamp. Engineered for professionals requiring accurate AC current measurements up to 2000 A, this tool ensures reliable data across complex environments. Its flexible, safety-rated design, compliant with EN standards, is perfect for industrial or laboratory settings.
Fluke i2000 Flex AC Current Clamp: A Versatile Tool for Precision Measurements
Elevate your current measurement capabilities with the robust and adaptable Fluke i2000 Flex AC Current Clamp. Engineered for professionals who demand accuracy and reliability, this clamp offers an effortless solution for measuring AC current in tight, hard to reach spaces. Boasting an AC current measurement range of up to 2000 A, the i2000 is compatible with a host of multimeters, recorders, and data loggers, making it an essential tool for any electrical technician.
Unmatched Flexibility and Precision
The Fluke i2000 Flex AC Current Clamp leverages the Rogowski principle to provide high flexibility in measuring electrical currents. With three different ranges—20 A, 200 A, and 2000 A—the clamp offers precise output sensitivities of 1 mV, 10 mV, and 100 mV per A. It delivers highly accurate readings with an impressive ±1% accuracy at +25°C, ensuring your data is reliable and consistent across all applications. The linearity is maintained within ±0.2% of reading, offering you peace of mind even in rigorous environments.
Innovative Design for Complex Environments
Designed with a maximum conductor diameter of 178 mm, the Fluke i2000 Flex can accommodate a wide range of conductor sizes without necessitating circuit breaks. Its flexible measuring head is not only lightweight but also allows for quick installation, even in complicated setups. Featuring an environmental operating temperature range of 0°C to +70°C, it stands prepared to handle diverse climatic conditions.
Built to Safety Standards
Safety is paramount when working with high voltages. The Fluke i2000 Flex AC Current Clamp is rated for CAT III 600 V, adhering to strict EN 61010 standards. This ensures that professionals can operate confidently, even when working on uninsulated conductors with voltages up to 600 V AC rms or DC and frequencies below 1 kHz. Additional features include a low battery indicator and a commendable power supply lifespan of 200 hours, powered by two AA batteries.
Comprehensive Specifications
Engineered for real-world application, this AC current clamp includes:
Head circumferences of 610 mm for versatile use.
A head cable diameter of 14.3 mm with a bend radius of 38.1 mm for easy maneuverability.
A cable length from head to electronics of 2 meters, allowing sufficient reach and flexibility.
Environmental and EMC compliance, with EN 61326 standards ensuring minimal external field influence.
Recommended Uses and Applications
The Fluke i2000 Flex is suited for both industry-grade applications and laboratory environments. Its design allows for efficient current monitoring without disrupting current flow, making it ideal for arduous tasks such as maintenance and diagnostics in industrial floors and large facilities. The clamp is also a dependable choice for professionals dealing with renewable energy sources and other high-power systems.
Invest in the Fluke i2000 Flex AC Current Clamp to guarantee precision, reliability, and efficiency in your electrical measurements. Elevate your productivity with a tool designed for the complexities of today’s electrical challenges.
Weight
0.1 kg
Specifications
Electrical specifications
Current ranges
20 A
200 A
2000 A
AC rms
Output sensitivity (AC-coupled)
1 mV
10 mV
100 mV
1 mV per A
Load impedance
100 kΩ minimum
Accuracy
at +25°C
±1% of range (45 Hz to 65 Hz)
Linearity
10% to 100% of range
±0.2% of reading
Noise
8 mV AC rms (30 A)
2 mV AC rms (300 A, 3000 A)
Frequency range
10 Hz to 20 kHz (-3 dB)
Phase error
< ±1° (45 Hz to 65 Hz)
±10° (at 20 kHz)
Position sensitivity (with cable > 25 mm from the coupling)
Position sensitivity: From 1% up to 3% of range with cable, depending on distance from the center (see figure left). Measurements closer than 25 mm from the coupling are typically greater than 3% of range.
External wire influence: 1% (-40 db) of external current >200 mm from head.
External field
with cable > 200 mm from the head
±1% of range
Power supply
2 x AA/MN 1500/LR6 Alkaline, 200 hours, low battery indicator
Temperature Coefficient
±0.08% of reading per °C
Working voltage
see Safety standards section
600 V AC rms or DC
General Specifications
Head Circumference
610 mm (24 in)
Head cable diameter
14.3 mm (0.56 in)
Head bend radius
38.1 mm (1.5 in)
Cable length (head to electronics)
2 m (6.56 ft)
Output connection
Molded 4 mm safety plugs (not integrated)
Operating temperature range
0°C to +70°C (32°F to 158°F) (head and electronics)
Storage temperature range
-40°C to +105°C (-40°F to 221°F) (head)
-20°C to +85°C (-4°F to 185°F) (electronics)
Operating humidity
15% to 85% (non-condensing)
Weight
180 g (6.34 oz) (head)
190 g (6.70 oz) (electronics)
Safety standards
EN 61010-031: 2002
EN 61010-2-032: 2002
EN 61010-1: 2001
600 Vrms, Category III, Pollution Degree 2
Use of the probe on uninsulated conductors is limited to 600 V ac rms or dc and frequencies below 1 kHz.
EMC standards
EN 61326: 1998 +A1, A2, and A3
Dimensions (H x W x D)
116 x 68.5 x 30 mm (4.56 x 2.69 x 1.18 in)
