FLUKE 289 True RMS Electronics Logging Multimeter

AUD $1,310.00 • ( AUD $1,441.00 inc. GST )

Free Delivery on orders over $500
Shipping time may vary for certain products*

  • Fast Delivery*
  • Technical Support
  • Product Training
  • Calibration Services*
  • Lowest Price Guaranteed
Click here to Make an Enquiry

Product Enquiry

If you would like more information regarding this product, simply email us here.
  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    Fluke 289 True RMS Electronics Logging Multimeter with TrendCapture is a 50,000 count DMM with a large LCD display, 200 hours of data recording, graphical trend display, CAT IV 600V, CAT III 1000V. Fluke 289 includes a 10mA source current for testing motor windings or contact resistance, a low pass filter for accuracy in ‘noisy’ environments and a low impedance voltage function for eliminating ghost voltages.

    SKU: Fluke 289 DMM Categories: , , Tag:

    The Fluke 289 is the top of the line handheld multimeter on the market.  Hands down this unit is tops in its class with a 50,000 count display, usb interface, advanced datalogging, and much more.  Find out why this unit is considered to be one of the best multimeters ever made period.

    The Fluke 289 Handheld Multimeter is one of the most powerful multimeters out there. The popular TrendCapture feature is a trend plot style graphical representation of a logged session that the meter has recorded, which is viewable right on the meter as soon as you complete your recording session. There’s no need to download and wait to see data, even after a 200 hour logging session. You just view it on location at the moment you end the session. You can even zoom in on the data at 5X magnification right on the meter! With multiple on-screen displays, a True-rms AC Bandwidth of 100kHz,  a logging memory of up to 10,000 readings, a low pass filter, and a minimum 100 hours battery life, you are ready to take on any job.

    Find Little Problems Before They Become Big Ones.

    The industrial meter for demanding users.

    New diagnostic functionality for maximizing productivity in the plant. The new 289 is the next generation high performance industrial logging multimeter designed to solve complex problems in electronics, plant automation, power distribution, and electro-mechanical equipment. With the ability to log data and review it graphically on-screen, you can solve problems faster and help minimize downtime. Let the new 289 be your watchdog for systems or processes while you are off solving other problems.

    Be sure to also check out the Fluke 287 True-rms Electronics Logging Multimeter with TrendCapture designed for electronics professionals.

    Maximize productivity with the combined Fluke 289 and FlukeView forms combo kit. With built-in data logger and TrendCapture capability, the 289 helps you track down elusive, intermittent problems, monitoring equipment with any of its functions while you do other jobs. Overlay your logged data from six meters or six time periods to find cause and effect relationships or for condition monitoring applications in FVF software. Turn your data into meaningful graphs and tables for a professional report. The 289/FVF combo kit gives you a practical & affordable approach to predictive maintenance.

    • FLUKE 289 True RMS Electronics Logging Multimeter
    • TrendCapture graphically displays logged data showing anomalies which may have occurred.
    • Zoom on trend up to 14 times
    • Selectable ac filter (Smoothing mode)
    • Adjustable recording and auto hold thresholds
    • Large 50,000 count, 1/4 VGA dot matrix display with white backlight
    • Logging function with expanded memory stores up to 15,000 recorded events before PC download
    • Two terminal 50 ohm range with 1 milliohm resolution, 10 mA source current.
    • Low Pass filter for accurate voltage and frequency measurements
    • LoZ Volts. Low impedance voltage function for eliminating ghost voltages.
    • “i” button. On board help screens for measurement functions.
    • Real time clock for automatic time stamping of saved readings
    • Relative mode to remove test lead resistance from low ohms or capacitance measurements
    • Measure up to 10 A (20 A for 30 seconds)
    • 100 mF capacitance range
    • Peak capture to record transients as fast as 250 µs
    DC volts 50.000 mV,500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0V @ 0.025% accuracy
    AC volts 50.000 mV,500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0V @ 0.4% accuracy (true-rms)
    DC current 500.00 µA, 5000.0 µA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A @ 0.15 % accuracy
    AC current 500.00 µA, 5000.0 µA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A @ 0.7% accuracy (true-rms)
    Temperature
    (excluding probe)
    -200.0 °C to 1350.0 °C (-328.0 °F to 2462.0 °F) @ 1.0 % accuracy
    Resistance 50.000 W (289 only), 500.00 W, 5.0000 kW, 50.000 kW, 500.00 kW, 5.0000 MW, 50.00 MW, 500.0 MW @ 0.05 % accuracy
    Capacitance 1.000 nF,10.00 nF 100.0 nF, 1.000 µF, 10.00 µF, 100.0 µF, 1000 µF, 10.00 mF, 100.00 mF @ 1.0 % accuracy
    Frequency 99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz @ 0.005 % + 1 accuracy
    Weight 1 kg
