Fluke 88-5 Deluxe Automotive Multimeter

AUD $1,110.00 .( AUD $1,221.00 inc. GST )


For all your equipment calibration needs, visit our MyCalibration website.


Free Delivery on orders over $1000
Shipping time may vary for certain products*

Product Enquiry

If you would like more information regarding this product, simply email us here.

  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    fluke logo

    The Fluke 88-5 Deluxe Automotive Multimeter offers measurement functions, troubleshooting capabilities, and levels of accuracy required for troubleshooting conventional and hybrid vehicles.

    Features:

    • Pulse width, duty cycle, Min/Max/Avg recording
    • 10 meg ohm input impedance won’t damage computer circuits
    • Large display and bright backlight for increased visibility
    • RPM measurements with optional inductive pickup
    • Pulse width measurements for fuel injector
    • Temperature measurements with optional temperature probe
    • Fluke’s limited lifetime warranty

    PDF download  Fluke-88-5-Datasheet

    With the Fluke 88-5 automotive multimeter, you can measure, troubleshoot, and find the solution for a number of problems that might occur with conventional and hybrid vehicles.

    Fluke’s 88-5 is the most powerful automotive multimeter they have ever produced. As well as the standard features of a multimeter, such as measuring voltage, current, continuity, and resistance, the Fluke 88V offers the following:

    • Pulse width
    • Duty cycle
    • Min/Max/Average recording
    • Diode tests
    • The pulse width function provides millisecond resolution for troubleshooting fuel injectors.
    • Automotive measurements
    • The Fluke 88V meter can take care of many automotive needs, getting into more of the digital multimeters measurement capabilities – it can measure voltage up to 1000 V AC and DC, current up to 10 A, 20 A for up to 30 seconds and frequency to 200 kHz and % duty cycle.

    Add those features to RPM measurements with optional inductive pickup and millisecond pulse width measurements for fuel injectors to name a few. The 88-5 comes packed with the functions you need:

    • Temperature measurements with optional temperature probe
    • Analogue bar graph to track changing or unstable signals
    • Min/Max/Average recording with Min/Max Alert to capture variations automatically
    • Peak Min/Max to record transients as fast as 250 μs
    • The 88V multimeter is designed for the garage
    • While working in a garage, the large display digits can help you focus on the vehicle while still being able to read the numbers. Plus, the two-level bright white backlight offers the additional visibility you may need.

    An optional magnetic hanger lets you hang the meter from most steel surfaces for easy set-up and viewing. The 88V is designed to be used in high energy environments like those found on hybrid vehicles.

    The product is supported by a limited lifetime warranty.

    Fluke 88V Deluxe Automotive Multimeter Includes:

    • Fluke 88V digital multimeter
    • High-impact holster
    • Test leads
    Weight 0.8 kg

    Specifications

    Technical Specifications
    DCV Maximum voltage 1000 V
    Accuracy ±(0.1% + 1)
    Best resolution 0.01 mV
    ACV Maximum voltage 1000 V
    Accuracy ±(0.5% + 2)
    AC bandwidth 5 kHz
    Best resolution 0.01 mV
    DC current Maximum amps 10 A
    Amps accuracy ±(0.4 % + 2)
    Best resolution 0.001 mA
    AC current Maximum amps 10 A
    Amps accuracy ±(1.2% + 2)
    Best resolution 0.001 mA
    Resistance Maximum resistance 50 MΩ
    Accuracy ±(0.4% + 1)
    Best resolution 0.1 Ω
    Capacitance Maximum capacitance 9,999 µF
    Accuracy ±(1% + 2)
    Best resolution 0.01 nF
    Frequency Maximum frequency 200 KHz
    Accuracy ±(0.005% + 1)
    Best resolution 0.01 Hz
    Duty cycle Maximum duty cycle 99.9%
    Accuracy within 2% per KHz + 0.1%
    Best resolution 0.1%
    Temperature measurement -200.0°C – 1090°C
    -328.0°F – 1994.0°F, 1.0% excluding probe
    80 BK temperature probe -40 °C – 260°C
    -40 °F – 500°F, 2.2°C or 2% whichever is greater
    Conductance Maximum conductance 60.00 nS
    Accuracy ±(1.0% + 10)
    Maximum resolution 0.01 nS
    Operating range Operating temperature -20°C – 55°C
    Storage temperature -40°C – 60°C
    Physical 5.2 x 9.8x 20.1 cm (2.06 x 3.86 x 7.93 in)
    624 g (22 oz.)
