REED R5050 TRMS 1000A AC/DC Clamp Meter

AUD $350.00 • ( AUD $385.00 inc. GST )

Free Delivery on orders over $500
Shipping time may vary for certain products*

  • Fast Delivery*
  • Technical Support
  • Product Training
  • Calibration Services*
  • Lowest Price Guaranteed
Click here to Make an Enquiry

Product Enquiry

If you would like more information regarding this product, simply email us here.
  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    mm_logo_04

    Authorised Australian Distributor.

    The REED Instruments R5050 is a professional grade True RMS AC/DC clamp meter that features a digital analog bargraph and a peak hold function.

    Features

    • Measures AC/DC current/voltage, resistance and frequency
    • 4000-count LCD display with analog bargraph
    • Low battery and overrange indicators
    • True RMS measurements
    • Min/Max, display hold, peak hold and relative mode
    • Diode test and continuity check functions
    • Cat. III 600V, Cat. II 1000V safety rating

    PDF download    R5050 Datasheet



    SKU: REED R5050 Categories: , Tags: , ,

    The REED Instruments R5050 is a professional grade True RMS AC/DC clamp meter that features a digital analog bargraph and a peak hold function.

    The REED Instrument R5050 is a durable True RMS auto-ranging clamp meter that can measure AC/DC current and voltage, resistance, and frequency. With a 4,000 count LCD display and a 42-segment analog bargraph, the R5050 features peak hold and min/max functions.

    Specifically designed for industrial maintenance personnel performing scheduled and preventive maintenance on electro-mechanical equipment and systems.

    Weight 0.15 kg

    Specifications

    AC/DC Current
    Range 40, 400, 1000A
    Accuracy AC: ±(1.9% rdg. +5 dgt.)
    DC: ±(2.5% rdg. +10 dgt.)
    Resolution 0.01, 0.1, 1A
    AC/DC Voltage
    Range AC: 400, 750V
    DC: 400, 1000V
    Accuracy AC: ±(1.5% rdg. +5 dgt.)
    DC: ±(1% rdg. +2 dgt.)
    Resolution 0.1, 1V
    Resistance
    Range 400, 4000Ω
    Accuracy ±(1% rdg. +3 dgt.)
    0.1, 1Ω
    Frequency
    Range 4kHz, 10kHz
    Accuracy ±(0.1% rdg. +1 dgt.)
    Resolution 1Hz, 10Hz
    General Specifications
    Range Selection Autoranging / Manual
    True RMS Yes
    Display 4,000 count LCD display
    Display Hold Yes
    Max/Min Yes
    Peak Hold Yes
    Zero Push Button Adjustment Yes
    Relative Mode Yes
    Diode Test Yes
    Analog Bargraph Yes (42-segment)
    Continuity Check Audible signal if resistance <100Ω
    Autoshut off Yes (after 30 mins)
    Power Supply 9V Battery
    Low Battery Indicator Yes
    Jaw Opening 1.5″ (40mm), up to 500 MCM
    Overvoltage Category CAT. III 600V, CAT. II 1000V
    Product Certifications CE
    Operating Temperature 32 to 104°F (0 to 40°C)
    Storage Temperature 14 to 140°F (-10 to 60°C)
    Dimensions 9.5x 2.6 x 1.4″ (242 x 66 x 36 mm)
    Weight 14oz (400g)
