KYORITSU 3132A Compact Insulation & Continuity Tester

AUD $320.00 • ( AUD $352.00 inc. GST )

Free Delivery on orders over $500
Shipping time may vary for certain products*

  • Fast Delivery*
  • Technical Support
  • Product Training
  • Calibration Services*
  • Lowest Price Guaranteed
Click here to Make an Enquiry

Product Enquiry

If you would like more information regarding this product, simply email us here.
  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.



    • Kyoritsu 3132A – 1000V Analogue Insulation-Continuity Tester
    • A highly compact and easy to use insulation and continuity tester.
    • Rugged Taut Band meter movement
    • Designed to strict CAT III 600V safety standards
    • IP54 RATED. The Kyoritsu 3132A has 3 insulation test ranges.
    • A 3 ohm continuity range and a 500 ohm resistance range.

        Kyoritsu-3132A-Datasheet

        Kyoritsu 3132A User Manual



    KYORITSU 3132A Compact Insulation & Continuity Tester

    • The Kyoritsu 3132A has always been a popular choice because of its price and simplicity for insulation testing.
    • Test Voltage: 250V / 500V / 1000V
    • Measuring Range: 100MΩ, 200MΩ, 400MΩ
    • Voltage Measuring Range – 0~600V AC
    • Easy to read scale means no confusing digital readings.
    • Zero out your trailing lead resistance so you don’t need to subtract the resistance of your trailing earth lead every time you test.
    • •1mA rated test current at the maximum resistance.
    • 200mA short circuit current on continuity testing.
    • Automatic discharge of circuit capacitance. (any charge stored in the circuit under test will be automatically discharged after testing.)
    • Live circuit warning buzzer and neon lamp.
    • Small and lightweight. Shock resistant new case material.
    • AC voltmeter with linear, easy-to-read scale.
    • CAT III 600V
    • Runs on 6 x AA batteries

    Why insulation testing is necessary?

    All live conductors of electrical appliances and installations must be insulated to prevent electric shock hazards from inadvertent contact or fire hazards from short circuit and equipment damage. In addition, a low insulation resistance can result in a leakage current which causes a waste of energy that increases the running costs of the installation.

    Insulation resistance must be checked by applying a higher voltage than the normal working voltage to ensure there is sufficient insulation.

    Periodic testing is also important to ensure that insulation of installations or appliances is not deteriorating. Foreign matter and mechanical factors like wear or breakage may reduce insulation resistance. Regular tests can detect possible fault in insulation.

    KYORITSU 3132A Technical specification

    Insulation Resistance Ranges
    Test Voltage 250V/500V/1000V
    Measuring Ranges 100MΩ/200MΩ/400MΩ
    Output Voltage on Open Circuit Rated Voltage +20%, -0%
    Nominal Current 1mA DC min
    Output Short Circuit Current 1.3mA DC approx.
    Continuity Test Ranges
    Measuring Ranges 3Ω/500Ω
    Output Voltage on Open Circuit 4.1V DC approx.
    Measuring Current 210mA DC min
    AC Voltage Range 0-600V AC
    General Specifications
    Power Source R6P (AA) (1.5V) x 6
    Dimensions (mm) 106 (L) 160 (W) 72 (D)
    Weight 560g approx.
    Weight 0.5 kg
