    HT INSTRUMENTS HT64 Digital Multimeter

    Its’s not by accident that the new series of HT60 series  professional multimeters are so rugged and well spec’d as they are the result of research conducted with the most demanding users of this kind of equipment, namely laboratories, where the choice of a measuring instrument is subject to strict tests concerning precision, reliability and safety of measurements even in extreme conditions.

    The HT Instruments new HT60 series is a complete range of professional CAT IV 600V multimeters, all able to measure in TRMS, autorange function is available on all models and with backlit display. The design is modern, but also ergonomic, to ensure maximum ease of use. They display with a high resolution, even in colour for the premium model HT64.

        HT64 Datasheet

        HT64 User Manual

    SKU: HT ITALIA HT64 Categories: , , Tag:

    HT ITALIA HT64 TRMS / CAT IV PROFESSIONAL DIGITAL MULTIMETER WITH DATA LOGGER FUNCTIONS.

    HT ITALIA HT64 Graphical Digital Multimeter

    The new HT ITALIA HT64 professional multimeter is the result of an in depth research conducted with the most demanding users of this kind of equipment, namely laboratories, where the choice of a measuring instrument is subject to strict tests concerning precision, reliability and safety of measurements even in extreme conditions. Therefore the HT 60 series is a complete range multimeters, all able to measure in TRMS, all with CAT IV 600V Safety Rating, autorange function available on all models, with backlight display.

    HT Italia HT64 Measurement Features:
    • DC voltage
    • AC, AC+DC TRMS Voltage
    • DC current
    • 4-20mA% display
    • AC, AC+DC TRMS current
    • Resistance and Continuity test
    • Diode test
    • Capacitance
    • Frequency
    • Duty Cycle
    • Temperature with K-type probe
    • Data Logger function and display of graphs of measured data

    These features that make this range of professional instruments unique and invaluable.

    HT ITALIA HT64 Graphics Digital Multimeter with Colour LCD display

    HT ITALIA HT64 Specifications:

    1. ELECTRICAL SPECIFICATIONS

    Accuracy calculated as ±[%reading + (num dgt * resolution)] at 18°C ¸ 28°C, <75%HR

    DC VOLTAGE
    Range Resolution Accuracy Input impedance Overload protection
    600.0mV 0.1mV ±(0.1%rdg+5dgt) 10MΩ 1000VDC/ACrms
    6.000V 0.001V
    60.00V 0.01V
    600.0V 0.1V ±(0.2%rdg+5dgt)
    1000V 1V



    AC TRMS VOLTAGE
    Range Resolution Accuracy (*)50Hz ¸ 60Hz Accuracy (*)61Hz ¸ 1kHz Overload protection
    600.0mV 0.1mV ±(0.9%rdg+5dgt) ±(3.0%rdg+5dgt) 1000VDC/ACrms
    6.000V 0.001V
    60.00V 0.01V
    600.0V 0.1V
    1000V 1V

    (*) Accuracy specified from 5% to 100% of measurement range, Input impedance: >9MΩ,

    Response time PEAK function: >1ms, Accuracy PEAK function: ±10%rdg

    AC+DC TRMS VOLTAGE
    Range Resolution Accuracy (*)50Hz ¸ 1kHz Input impedance Overload protection
    6.000V 0.001V ±(3.0%rdg+20dgt) >9MΩ 1000VDC/ACrms
    60.00V 0.01V
    600.0V 0.1V
    1000V 1V
    DC CURRENT
    Range Resolution Accuracy Overload protection
    600.0mA 0.1mA ±(0.9%rdg+5dgt) Fast Fuse 0.8A/1kVAC/DC (inputs mA, mA)
    6000mA 1mA
    60.00mA 0.01mA
    600.0mA 0.1mA ±(0.9%rdg+8dgt)
    10.00A 0.01A ±(1.5%rdg+8dgt) Fast Fuse 10A/1kVAC/DC (input 10A)
    AC, AC+DC TRMS CURRENT
    Range Resolution Accuracy (*)50Hz ¸ 1kHz Overload protection
    600.0mA 0.1mA ±(1.2%rdg+5dgt) Fast Fuse 0.8A/1kVAC/DC (inputs mA, mA)
    6000mA 1mA
    60.00mA 0.01mA
    600.0mA 0.1mA
    10.00A 0.01A ±(1.5%rdg+5dgt) Fast Fuse 10A/1kVAC/DC (input 10A)

    (*)Accuracy specified from 5% to 100% of measurement range

    Response time PEAK function: >1ms, Accuracy PEAK function: ±10%rdg

    AC+DC TRMS Current: accuracy (50Hz¸1kHz): ±(3.0%rdg + 20dgt)

    4-20mA% READINGS
    Range Resolution Accuracy Reading
    -25% ÷ 125% 0.1% ±50dgt 0mA=-25%, 4mA=0%, 20mA=100%, 24mA=125%
    DIODE TEST
    Range Max test current Open voltage Overload protection
    <1.5mA 3.2V 1000VDC/ACrms
    RESISTANCE AND CONTINUITY TEST
    Range Resolution Accuracy Buzzer Overload protection
    600.0Ω 0.1Ω ±(0.8%rdg+10dgt) <50Ω 1000VDC/ACrms
    6.000kΩ 0.001kΩ ±(0.8%rdg+5dgt)
    60.00kΩ 0.01kΩ
    600.0kΩ 0.1kΩ
    6.000MΩ 0.001MΩ
    60.00MW 0.01MΩ ±(2.5%rdg+10dgt)



    FREQUENCY (Electronic circuits)
    Range Resolution Accuracy Sensitivity Overload protection
    60.00Hz 0.01Hz ±(0.09%rdg+5dgt) 2Vrms min(20% < duty < 80%, <100kHz)

    5Vrms min

    (20% < duty < 80%, >100kHz)

    1000VDC/ACrms
    600.0Hz 0.1Hz
    6.000kHz 0.001kHz
    60.00kHz 0.01kHz
    600.0kHz 0.1kHz
    1.000MHz 0.001MHz



    FREQUENCY (Electrical circuits)
    Range Resolution Accuracy Sensitivity Overload protection
    40Hz ¸ 10kHz 0.01Hz¸0.001kHz ±(0.5%rdg) 2Vrms 1000VDC/ACrms



    DUTY CYCLE
    Range Resolution Accuracy Overload protection
    0.1 ¸ 99.9% 0.01% ±(1.2%rdg+2dgt) 1000VDC/ACrms

    Pulse frequency range: 40Hz ¸ 10kHz, Pulse width: ±5V (100ms ¸ 100ms)



    CAPACITANCE
    Range Resolution Accuracy Overload protection
    60.00nF 0.01nF ±(1.5%rdg+20dgt) 1000VDC/ACrms
    600.0nF 0.1nF ±(1.2%rdg+8dgt)
    6.000mF 0.001mF ±(1.5%rdg+8dgt)
    60.00mF 0.01mF ±(1.2%rdg+8dgt)
    600.0mF 0.1mF ±(1.5%rdg+8dgt)
    6.000mF 0.001mF ±(2.5%rdg+20dgt)



    TEMPERATURE WITH TYPE K PROBE
    Range Resolution Accuracy (*) Overload protection
    -40.0°C ÷ 600.0°C 0.1°C ±(1.5%rdg+3°C) 1000VDC/ACrms
    600°C ÷ 1350°C 1°C
    -40.0°F ÷  600.0°F 0.1°F ±(1.5%rdg+5.4°F)
    600°F ÷  2462°F 1°F

    (*)Accuracy referred to instrument without probe

    HT Italia HT64  GENERAL SPECIFICATIONS:

    Display:

    • TFT LCD, colours, 4½ dgt, 6000 counts, decimal point and bargraph
    • Automatic polarity indication
    • Backlight
    • OL” over range indication
    • Response time: 3/s

    HT ITALIA HT64 Graphics Digital Multimeter with rechargeable battery





    Weight .5 kg
