Tenmars TM-1017 400A True-Rms with Phase Rotation Clamp Meter

AUD $398.00 • ( AUD $437.80 inc. GST )

Free Delivery on orders over $500
Shipping time may vary for certain products*

  • Fast Delivery*
  • Technical Support
  • Product Training
  • Calibration Services*
  • Lowest Price Guaranteed
Click here to Make an Enquiry

Product Enquiry

If you would like more information regarding this product, simply email us here.
  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    The Tenmars TM-1017 clamp meter can measure AC current of up to 400A, and can measure AC and DC voltage, resistance, continuity and frequency.

    The TM-1017 can also measure active power, reactive power and apparent power, energy as well as power factor on single and three phase systems with a maximum conductor size of 30mm.

    Features:

    • Measures AC current up to 400A
    • Measures AC and DC voltage up to 600V
    • Active, Reactive and Apparent Power
    • Power Factor
    • Energy
    • Phase sequence and rotation
    • Maximum conductor size – 30mm
    • Harmonics to 25th order
    • Total Harmonic Distortion
    • Resistance
    • Continuity
    • Frequency
    • Auto Ranging
    • Backlit LCD display with segmented bar graph
    • Peak Hold
    • MAX / MIN functions
    • Data Hold (freezes the display)

    Authorised Australian Distributor

    WARRANTY 3

    The Tenmars TM-1017 clamp meter can measure AC current of up to 400A, and can measure AC and DC voltage, resistance, continuity and frequency. The TM-1017 can also measure active power, reactive power and apparent power, energy as well as power factor on single and three phase systems with a maximum conductor size of 30mm.

    Phase sequence and rotation is also possible with the Tenmars TM-1017 and the user can also measure harmonics to 25th order with total harmonic distortion (THD). Information is presented on a digital LCD display with backlight and bargraph.

    Maximum, minimum, and peak hold functions are standard on the Tenmars TM-1017 for capture of peak currents, or max/min readings. This is an autoranging meter, which removes the need to select the correct range when using a particular function as the TM-1017 does this automatically to suit the measurement.

    The Tenmars TM-1017 is supplied complete in carry pouch with factory calibration certificate, user manual, battery and test leads.

    Specifications
    Maximum Current 400 Amps
    Display Counts 10000 (Backlit LCD display)
    Maximum Conductor Size 30mm
    AC Current Range 0.1A to 400A, ±(1.0% of rdg + 3 dgts)
    AC Voltage Range 0.1V to 599.9V, ±(1.0% of rdg + 3 dgts)
    DC Voltage Range 0.1V to 599.9V, ±(1.0% of rdg + 3 dgts)
    Resistance 0.1 ohm to 1999 ohms ±(1.0% of rdg + 5 dgts)
    Continuity Buzzer Yes
    Frequency 40Hz to 399.9 Hz ±(0.5% of rdg + 1 dgt)
    Bargraph Yes
    Autoranging Yes
    Auto Power Off Yes
    Peak Hold Yes
    Data Hold Yes
    Min/Max Yes
    Power Supply 2 1.5V type ‘AAA’ batteries
    Dimensions 205mm (L) x 64mm (W) x 39MM (D)
    Weight 280g approx. including batteries
    Weight .5 kg
