KYORITSU 1018 Pocket Digital Multimeter

AUD $105.00 • ( AUD $115.50 inc. GST )

Free Delivery on orders over $500
Shipping time may vary for certain products*

  • Fast Delivery*
  • Technical Support
  • Product Training
  • Calibration Services*
  • Lowest Price Guaranteed
Click here to Make an Enquiry

Product Enquiry

If you would like more information regarding this product, simply email us here.
  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    The Kyoritsu is available in two styles, the 1018S (Soft case type) and the  1018H (Hard case type).


    • Display : 4000 counts.
    • Auto range.
    • Diode test feature.
    • Capacitance test feature.
    • Continuity test.


    The KYORITSU 1018 Pocket Digital Multimeter is a pocket-sized meter that comes complete with a hard or soft case. the 1018 is capable of measuring both AC & DC voltages up to 600V as well as testing resistances up to 40MΩ. The KYORITSU 1018 also also features diode test and frequency measurement function as well as capacitance measurement up to 200μF.

    Satey rated to IEC 61010-1 CAT III 300V, the Kyoritsu 1018 autoranging multimeter has a 4000 count digital display and includes a continuity test feature which warns the user with an audible buzzer below 120Ω.

    KYORITSU 1018 Pocket Digital Multimeter Specifications:

    DC V 400mV/4/40/400/600V (Input Impedance 10MΩ)
    ±0.8%rdg±5dgt (400mV/4/40/400V)
    ±1.0%rdg±5dgt (600V)
    AC V 4/40/400/600V (Input Impedance 10MΩ)
    ±1.3%rdg±5dgt (4/40V)
    ±1.6%rdg±5dgt (400/600V)
    Ω 400Ω/4/40/400kΩ/4/40MΩ
    ±1.0%rdg±5dgt (400Ω/4/40/400kΩ/4MΩ)
    ±2.5%rdg±5dgt (40MΩ)
    Continuity buzzer 400Ω (Buzzer sounds below 120Ω)
    Diode test 4V Release Voltage:Approx. 0.4mA Test Current
    Capacitance 4nF/40nF/400nF/4µF/40µF/200µF
    Frequency 10/100Hz/1/10/100/200kHz
    Applicable standards IEC 61010-1 CAT III 300V
    IEC 61010-2-031
    IEC 61326-1
    Display 4000 counts
    Power source LR44 (1.5V) × 2
    Dimensions 107(L) × 54(W) × 10(D)mm
    Weight 70g approx.
    Included Accessories LR44× 2
    Instruction Manual
    1018H (Hard Case)
    Weight .3 kg
