IDEAL 33-866 -| Test-Tone-Trace VDV Kit

AUD $260.00 .( AUD $286.00 inc. GST )


For all your equipment calibration needs, visit our MyCalibration website.


Free Delivery on orders over $1000
Shipping time may vary for certain products*

Product Enquiry

If you would like more information regarding this product, simply email us here.

  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    Ideal electrical logo

    If you’re looking for an affordable, all-in-one solution for testing and toning twisted pair or coax cable, then the IDEAL 33-866 Test-Tone-Trace VDV kit is the perfect choice. This kit includes our popular 33-856 VDV Multimedia tester and the 62-164 Amplifier Probe, plus several other essential accessories. It’s ideal for any low voltage, video, or data communications installer who needs a reliable, easy-to-use solution for testing cable on a daily basis. With the IDEAL 33-866 Test-Tone-Trace VDV kit, you’ll be able to quickly and easily test for continuity, shorts, and grounds; trace cables without initiating calls; verify pairs with distortion measurements; and tone complex cable installations with up to eight individual tones.

    3 Year Warranty / Rapid-Tech Exclusive Warranty /

    PDF download IDEAL 33-866 Test Tone Trace Kit Datasheet

    Key Features:

    • Test cables, Tone cables, and Trace cables in one kit
    • Voice/Data/Video LCD based wire mapper verifies cable continuity
    • Identifies errors by pin: shorts, opens, miswires, reversals, and split pairs
    • Amplifier probe included
    • Designed for Cat 3/5/5e/6/6a cables; RG59/6/ 6 Quad
    • RJ-45; RJ-11/12; and Female F port interfaces

    The IDEAL 33-866 Test-Tone-Trace VDV Kit is the perfect tool for any low voltage, video, or data communications installer. This all-in-one kit combines our popular 33-856 VDV Multimedia Tester and the 62-164 Amplifier Probe, plus several accessories, to provide everything you need for basic testing and toning applications. The kit is affordably priced and comes with a carrying case for easy transport and storage.

    The IDEAL 33-866 Test-Tone-Trace VDV Kit is an all-in-one basic Voice-Data-Video tester that is perfect for verifying the wiring of low-voltage and data communications cables. The primary function of the VDV is the wiremap test, which shows pin by pin whether a cable is terminated properly at both ends and if there is continuity from end to end. The VDV can test Data/Ethernet RJ-45 (8P8C), Voice/Phone RJ-11/12(6P6C/6P4C) and Video/coax cables. The LCD display will show “PASS” or “ERROR” after each test, making it easy to see if the cable is terminated correctly.

    In Data mode, the RJ-45 port tests RJ-45 connector cables terminated to Cat 3/5/5e/6/6a twisted pair cables. When the test is activated, VDV checks each conductor of the cable for any opens (unterminated or cut conductors), shorts (cut or nicked conductors that come into contact), miswires (wires out of order – not consistent at both ends), reversals, or split pairs (wired correctly but using wrong conductor order and grouping). VDV can accurately identify and alert the user to uplink/crossover cables.

    • Test results are displayed on the LCD in a pin-to-pin format. Error types are also displayed on the LCD. Shield continuity can also be tested on shielded RJ-45 connectors and cables.
    • In Voice mode, the RJ-11/12 port is active. Testing is similar to the Data test, but tests up to 6 conductors instead of 8.
    • In Video mode, the F port is active. Coax cables are tested for opens and shorts on the pin and shield.
    • For all tests, the included main remote (Remote #1) is used to terminate the far end of the cable run. The main remote is stored in the base of the tester when not in use.
    • A built in analog tone generator is also included and can be used in all testing modes. The tone generator has 4 user selectable tones. Toning helps to locate and identify a single cable that is within a bundle of cables. The tone generator has the ability to tone by pin, by pair, or all conductors at once. This allows the user to more precisely locate errors within the cable, such as finding opens.
    • The 62-164 Pro Amplifier Probe is used to audibly amplify analog signals generated by standalone or built-in IDEAL tone generators. The probe has an adjustable volume control knob.
    • The probe tip is plastic to trace and identify cables within a bundle. The plastic tip also prevents sparking in energized systems.
    • Test cables, Tone cables, and Trace cables in one kit
    • Voice/Data/Video LCD based wiremapper verifies cable continuity
    • Identifies errors by pin: shorts, opens, miswires, reversals, and split pairs
    • Amplifier probe included
    • Designed for Cat 3/5/5e/6/6a cables; RG59/6/ 6 Quad
    • RJ-45; RJ-11/12; and Female F port interfaces
    • Tone generator with 4 selectable tones
    • Main remote included
    • Carrying case with patch cables, alligator clips, BNC and RCA adapters included
    • Testers use 9V batteries – included
    Weight .8 kg
