    The Fluke 424D laser distance meter is the perfect tool for anyone who needs to quickly and easily measure distances. This advanced laser measuring tool can accurately measure distances up to 100 meters, making it ideal for a wide range of applications. Plus, with its extra features, the 424D is perfect for getting accurate measurements in hard-to-reach locations.



    PDF download   Fluke 424D Datasheet



    With the Fluke 424D Laser Distance Meter, you can measure distances up to 100 meters with high accuracy

    The Fluke 424D is our most advanced laser distance meter. It has many features that will save you time in different situations and reduce errors.

    With this laser measuring tool, you can just point and click to instantly measure distances up to 100 meters (330 ft.) with accuracy of +1 millimeter. There is no need to interpret scales or worry about making mistakes. The extra bright laser makes it easy to target even at longer distances.

    The 424D laser distance meter has extra features that make it easy to get accurate measurements in hard-to-reach locations. These include a 180º inclination sensor, the corner angle feature, and a built-in compass. The large, four-line backlit display makes it easy to see the results. This tool will help you do the work of two people on your own.

    Fluke 424D helpful features:

    • Provides a compass “heading” for distance measurement
    • Provides easy to-use addition and subtraction function
    • Includes automated end-piece correction. When measuring from an edge or corner, a built-in sensor detects the position of this bracket and automatically changes the reference point.
    • Provides audible keypad feedback
    • Offers improved visibility with a bigger, 4-line backlit display
    • Improved battery life of 5000 measurements with automatic shut-off feature
    • Offers minimum/maximum tracking to measure the room’s diagonal and horizontal distance from a stable measurement point
    • Allows mounting on a tripod for stable long distance measurements
    • Includes stake out function for marking off defined measured lengths
    • Stores the last twenty measurements for quick recall
    • Strong environmental protection with IP54 (water spray and dust proof) sealing
    • Powered by two AAA batteries
    • Comes with carrying pouch and three-year warranty
    Weight 0.3 kg

    Specifications

    Fluke 424D Specifications:

    Distance Measurement

    Typical measuring tolerance 1 ±1.0 mm 3
    Maximum measuring tolerance 2 ±2.0 mm 3
    Range At Leica Target Plate GZM26 100 m
    Typical range 1 80 m
    Range at unfavorable condition 4 60 m
    Smallest unit displayed 6 / 30 / 60 mm (10 / 50 / 100 m)
    Ø Laser point at distances 6 / 30 / 60 mm (10 / 50 / 100 m)

    Tilt Measurement

    Measuring tolerance to laser beam 5 ±0.2°
    Measuring tolerance to housing 5 ±0.2°
    Range 360°

    General

    Laser cass 2
    Laser type 635 nm, < 1 mW
    Protection class IP54
    Automatic laser off After 90 seconds
    Automatic power off After 180 seconds
    Battery life (2 x AAA) 1.5 V NEDA 24A/IEC LR03 Up to 5,000 measurements
    Size (L x W x D) 127 x 56 x 33 mm
    Weight (with batteries) 158 g
    Temperature range Storage operation -25°C to +70°C
    -10°C to +50°C
    Calibration cycle Tilt and compass
    Maximum altitude 3000 m
    Maximum relative humidity 85% at -7°C to 50°C
    Safety IEC Standard No. 61010-1:2001
    EN60825-1:2007 (Class II)
    EMC EN 55022:2010
    EN 61000-4-3:2010
    EN 61000-4-8:2010
    1. APPLIES FOR 100% TARGET REFLECTIVITY (WHITE PAINTED WALL), LOW BACKGROUND ILLUMINATION, 25°C.
    2. APPLIES FOR 10 TO 500% TARGET REFLECTIVITY, HIGH BACKGROUND ILLUMINATION, -10°C TO +50°C.
    3. TOLERANCES APPLY FROM 0.05 M TO 10 M WITH A CONFIDENCE LEVEL OF 95%. THE MAXIMUM TOLERANCE MAY DETERIORATE TO 0.1 MM/M BETWEEN 10 M TO 30 M AND TO 0.15 MM/M FOR DISTANCES ABOVE 30 M.
    4. APPLIES FOR 100% TARGET REFLECTIVITY, BACKGROUND ILLUMINATION BETWEEN 10’000 LUX AND 30’000 LUX.
    5. AFTER USER CALIBRATION. ADDITIONAL ANGLE RELATED DEVIATION OF ±0.01° PER DEGREE UP TO ±45° IN EACH QUADRANT. APPLIES AT ROOM TEMPERATURE. FOR THE WHOLE OPERATING TEMPERATURE RANGE THE MAXIMUM DEVIATION INCREASES BY ±0.1°.
