Fluke T6-1000 PRO Electrical Tester with Visual Continuity™
Fluke Sale - Save Up to 20%
Original price was: $577.00.$502.00Current price is: $502.00. .( $552.20 inc. GST )
For all your equipment calibration needs, visit our MyCalibration website.
Free Delivery on orders over $1000
Shipping time may vary for certain products*
Product Enquiry
If you would like more information regarding this product, simply email us here.
Fluke T6-1000 PRO Electrical Tester with FieldSense™ technology. Measure voltage/current simultaneously without direct contact. Fast delivery available.
The Fluke T6-1000 PRO Electrical Tester revolutionises electrical troubleshooting with its groundbreaking FieldSense™ technology, enabling simultaneous voltage and current measurements without direct electrical contact. This advanced electrical tester eliminates the need for circuit breaking, significantly reducing downtime whilst enhancing safety protocols for industrial professionals.
Unparalleled Precision in Challenging Environments
Designed for engineers and technicians working with motors, pumps, and complex electrical systems, this professional voltage tester delivers accurate readings up to 1000V AC and 200A AC. The innovative FieldSense™ technology detects electrical signals through insulation, allowing measurements on live wires without probe contact—a game-changer for troubleshooting in confined spaces or hazardous environments.
Enhanced Productivity Features
The T6-1000 PRO’s simultaneous voltage and current display provides comprehensive electrical insights instantly. Its rugged construction withstands harsh industrial conditions, featuring a CAT IV 600V, CAT III 1000V safety rating that meets the stringent demands of mining, manufacturing, and renewable energy applications.
Key operational advantages include:
- Open jaw design accommodating conductors up to 17.8mm diameter
- Bright LED indicators ensuring visibility in low-light industrial settings
- Auto-ranging capabilities eliminating manual range selection for faster diagnostics
- Data logging functionality capturing intermittent faults often missed during routine inspections
Streamlined Procurement Integration
For procurement professionals managing bulk electrical testing equipment orders, the Fluke T6-1000 PRO offers exceptional value through reduced training requirements and standardised testing protocols across facilities. Its intuitive interface minimises learning curves, whilst robust construction ensures long-term reliability—critical factors when specifying equipment for multi-site operations.
The integrated wireless connectivity enables seamless data transfer to maintenance management systems, supporting predictive maintenance strategies that reduce unplanned downtime. This connectivity proves invaluable for utilities and telecommunications companies requiring comprehensive equipment performance documentation.
Professional-Grade Reliability
Built on Fluke’s decades of electrical measurement expertise, this electrical testing instrument incorporates advanced signal processing algorithms that filter electrical noise, ensuring accurate readings in electromagnetically challenging environments. The ergonomic design reduces operator fatigue during extended troubleshooting sessions, whilst the replaceable jaw mechanism extends operational life.
For teams managing critical infrastructure—from industrial automation systems to defence installations—the Fluke T6-1000 PRO Electrical Tester represents an essential diagnostic tool that combines cutting-edge technology with proven reliability. Its comprehensive measurement capabilities support efficient fault diagnosis, ultimately maintaining operational excellence across diverse industrial applications.
Transform your electrical troubleshooting approach with precision, safety, and efficiency that only advanced FieldSense™ technology can deliver.
| Weight | 1 kg |
|---|
- Revolutionary FieldSense™ Technology – Measure voltage and current simultaneously through wire insulation without breaking circuits, eliminating downtime and enhancing safety during live troubleshooting operations.
- Simultaneous Voltage & Current Display – View both measurements on a single screen for comprehensive electrical analysis, enabling faster fault diagnosis and reducing the need for multiple testing instruments.
- Open Jaw Design with 17.8mm Capacity – Accommodate various conductor sizes without disconnecting wires, making it ideal for motor control centres, distribution panels, and industrial equipment maintenance.
- High Safety Rating (CAT IV 600V, CAT III 1000V) – Meets stringent industrial safety standards for hazardous environments including mining, utilities, and heavy manufacturing applications.
- True RMS Measurements up to 1000V AC/200A AC – Deliver precise readings on non-linear loads and variable frequency drives, ensuring accurate diagnostics in complex industrial systems.
- Rugged Construction with Bright LED Indicators – Withstand harsh industrial conditions whilst maintaining visibility in low-light environments, reducing operator fatigue during extended troubleshooting sessions.
- Data Logging and Wireless Connectivity – Capture intermittent faults and transfer results directly to maintenance management systems, supporting predictive maintenance strategies and regulatory compliance documentation.
Technical Specifications
|
Parameter |
Specification |
|---|---|
|
Voltage Measurement |
1000V AC (True RMS) |
|
Current Measurement |
200A AC (True RMS) |
|
Frequency Range |
45 Hz to 66 Hz |
|
Jaw Capacity |
17.8 mm (0.7 in) diameter maximum |
|
Safety Rating |
CAT IV 600V, CAT III 1000V |
|
Accuracy (Voltage) |
±3.0% + 10 counts (45-66 Hz) |
|
Accuracy (Current) |
±3.0% + 5 counts (10-200A, 45-66 Hz) |
|
Operating Temperature |
-10°C to +50°C (14°F to 122°F) |
|
Storage Temperature |
-40°C to +60°C (-40°F to 140°F) |
|
Humidity |
Non-condensing <95% (10°C to 30°C)Non-condensing <75% (30°C to 40°C)Non-condensing <45% (40°C to 50°C) |
|
Display |
LCD with LED backlight |
|
Display Resolution |
6000 count |
|
Auto-ranging |
Yes |
|
Data Hold |
Yes |
|
Battery Type |
3 × AA alkaline batteries |
|
Battery Life |
Approximately 8 hours continuous use |
|
Dimensions |
270 mm × 75 mm × 40 mm (10.6 in × 2.9 in × 1.6 in) |
|
Weight |
0.609 kg (1.34 lbs) |
|
Drop Test |
1 metre |
|
IP Rating |
IP42 |
|
Compliance |
IEC 61010-1, IEC 61010-2-032, IEC 61326-1 |
|
Warranty |
2 years |
FieldSense™ Technology Features
|
Feature |
Specification |
|---|---|
|
Measurement Method |
Non-contact voltage and current detection |
|
Wire Insulation |
Works through standard wire insulation |
|
Signal Processing |
Advanced filtering for electrical noise immunity |
|
Simultaneous Display |
Voltage and current measurements shown concurrently |
|
Open Jaw Design |
Accommodates various conductor configurations |
Frequently Asked Questions – Fluke T6-1000 PRO Electrical Tester
1. How does FieldSense™ technology work and what makes it different?
FieldSense™ technology enables the T6-1000 PRO to measure voltage and current simultaneously through wire insulation without direct contact. This proprietary Fluke technology uses advanced signal processing to detect electrical fields around conductors, allowing measurements on live circuits without breaking connections or removing wire nuts. Unlike traditional clamp meters that require exposed conductors, FieldSense™ works through standard electrical insulation, significantly reducing testing time and eliminating the need for circuit interruption.
2. Is the Fluke T6-1000 PRO safe to use on high-voltage systems?
Yes, the T6-1000 PRO meets stringent safety standards with CAT IV 600V and CAT III 1000V ratings, making it suitable for industrial environments including distribution panels, motor control centres, and utility installations. The instrument’s non-contact measurement capability further enhances safety by eliminating direct electrical contact during testing. The rugged construction includes overvoltage protection and has been tested to withstand harsh industrial conditions, ensuring reliable operation in demanding electrical environments.
3. What wire sizes and conductor types are compatible with the open jaw design?
The T6-1000 PRO accommodates conductors up to 17.8mm (0.7 inches) in diameter within its open jaw design. This capacity covers most standard electrical cables including single conductors, bundled wires, and armoured cables commonly found in industrial applications. The open jaw design works with insulated wires, bare conductors, and various cable configurations, making it versatile for motor testing, panel troubleshooting, and distribution system diagnostics across different installation types.
4. How accurate are the measurements and what factors affect performance?
The T6-1000 PRO delivers True RMS measurements with ±3.0% accuracy for voltage (±10 counts) and current (±5 counts) within its specified operating range of 45-66 Hz. Accuracy remains consistent across the full measurement range of 1000V AC and 200A AC. Environmental factors such as electromagnetic interference are minimised through advanced signal filtering, whilst proper jaw positioning around the conductor ensures optimal performance. Regular calibration maintains measurement accuracy over the instrument’s operational lifetime.
5. What maintenance is required to keep the T6-1000 PRO functioning properly?
Routine maintenance involves keeping the jaw mechanism clean and checking battery levels regularly. The replaceable jaw design extends operational life – inspect for wear or damage that could affect measurement accuracy. Store the instrument in dry conditions within the specified temperature range and avoid exposure to corrosive chemicals. Battery replacement typically occurs after approximately 8 hours of continuous use. Annual calibration by qualified service centres ensures measurement accuracy and compliance with safety standards, particularly important for regulatory documentation requirements.
