The Yokogawa CA550-F2 Multi-Function Process Calibrator with HART Communication Function is the perfect tool for any professional looking to achieve accurate and reliable results in their field work. This high-performance calibrator offers advanced source and measurement accuracy, allowing you to calibrate even the most sensitive field instruments with confidence. In addition, the CA550 boasts a variety of useful functions that make it ideal for use in multiple applications, making it a truly versatile and essential tool for any professional.
The Yokogawa CA550 is an advanced piece of equipment that offers automatic input/output testing for calibrations targets. This product is perfect for those who need to save time and ensure accurate results. The CA550 main unit saves calibration results, such as the generated value, measured value, error rate, date/time, and pass/fail in CSV format. In addition, the CA550 can be connected to a PC using a standard USB cable. It can also be used as a mass storage device, making it easy to transfer data to the PC.
The CA500 has a Reflective LCD, which provides improved outdoor visibility. With a main display for generated/measured values and a sub display for %, mV, Ω, etc. the CA550 allows you to quickly and easily confirm all the information you need at a work site.
This innovative device allows you to see a wiring diagram displayed according to the function you’ve selected, making it easy to ensure that you’re connecting everything correctly. This prevents the risk of mis-wiring and makes your job much easier overall.
Using a TC Mini Plug together with a compensating lead wire enables generation of thermal electromotive force without an external RJ sensor.*
* A compensating lead wire needs to be prepared by customer.
The source can be easily switched between 0% and 100% of range.
Users can also set a desired value.
The output is changed in preset steps by pressing UP or DOWN key.
Keys related to generation and measurement are arranged collectively to allow easy and intuitive operation.
For 4-20 mA, 1-5 V ranges, users can choose between LINEAR and SQUARE ROOT output.
Weight | 1 kg |
---|
Common Specifications
Source
Generation unit voltage limiter |
Approx. −5 V to +36 V |
Generation unit current limiter |
Approx. ±30 mA |
Sweep function |
Step/Linear/Program |
Interval time |
5 to 600 s |
Generation load condition |
C ≤10 μF, L ≤10 mH |
Output resistance |
20 mΩ or less |
Output response time |
DC Voltage/Current/TC: Approx. 250 ms RTD/Resistance: Approx. 1 ms |
Measurement
CMRR |
120 dB (50/60 Hz) |
NMRR |
60 dB (50/60 Hz) |
Rating between terminals |
H/L terminals: 50 V LOOP/mA terminals: 30 V mA/L terminals: 50 mA |
Current terminal protective input |
|
PTC protection |
|
Maximum voltage application between measurement terminals and earth |
|
50 V peak |
General Specifications
Function |
CA500 |
CA550 |
Display |
Monochrome Dot Matrix LCD |
|
Built-in light |
Selection of “Constantly ON”, “Constantly OFF” or “Auto off by approx. 10 min” OFF, level dimming function |
|
Display refresh rate |
Approx. 1 s |
|
Warm-up time |
Approx. 5 min |
|
Language |
English (default setting), Japanese, Chinese, Korean, Russian |
|
Power supply |
DC 5 V±10%, max. 500 mA, Four alkaline AA batteries, Battery life: Approx. 16 hours (Measurement ON, 5 V output/10 kΩ or more) |
|
Auto power-off |
Approx. 30 minutes (disabled by default) |
|
Ground voltage |
Measurement terminal: 50 V, Source terminal: 30 V |
|
Insulation resistance |
Between FUNCTION1-2 terminals: DC 500 V 50 MΩ or more |
|
Withstand voltage |
Between FUNCTION1-2 terminals: 500 V AC for 10 seconds |
|
Dimensions |
Approx. 130 (W) × 260 (H) × 53 (D) mm |
|
Weight |
Approx. 900 g (including batteries) |
|
Safety standard |
EN61010-1, Overvoltage Category I, Pollution Degree 2 EN61010-2-030, Measurement category O (other) |
|
Operation environment |
Temperature: −10 to +50˚C, Humidity: 80%R.H. (40˚C or less), 50%R.H. (40 to 50˚C) *No condensation, Altitude: 2000 m or less |
|
Storage environment |
Temperature: −20 to +60˚C, Humidity: 90%R.H. (No condensation) |
|
Interface |
USB B communication device class |
USB B communication device class, USB B mass storage class |
Application |
— |
HART communication mode |
Number of Data Records |
Up to 100 results |
Up to 250 CSV files |
Accessories |
Source lead cables, Measurement lead cables, Binding post (2 sets), USB cable (2 m, USB Type A – USB Type B), Soft case (for accessories), four AA alkaline batteries, Instruction manual (CD), Startup guide, Shoulder strap |
