KohTect 107VF Handheld Vibration tester

AUD $1,950.00 .( AUD $2,145.00 inc. GST )


For all your equipment calibration needs, visit our MyCalibration website.


Free Delivery on orders over $1000
Shipping time may vary for certain products*

Product Enquiry

If you would like more information regarding this product, simply email us here.

  • Drop files here or
    Accepted file types: jpg, gif, png, pdf, Max. file size: 1 MB, Max. files: 4.
    • This field is for validation purposes and should be left unchanged.

    KohTect logo

    The KohTect 107VF is a portable vibration meter that offers comprehensive measurement capabilities. It is designed to evaluate rotational machinery using FFT spectrum analysis and compare results against ISO 10816 standards. Additionally, it supports route-based measurements and data collection with a user-friendly methodology. Explore the KohTect 107VF for efficient vibration analysis and monitoring.

    3 Year Warranty

    PDF download  107VF User Manual

    Compact yet powerful, the KohTect 107VF vibration meter

    The KohTect 107VF handheld vibration meter measures overall vibration parameters, can test the FFT spectrum of rotational machinery, provides immediate evaluation against ISO 10816 standards, and performs route-based measurements and data collection using route-based measurement methodology. Data files and route files can be exchanged via email, making this tool perfect for collecting data at a distance. 107VF hand held vibration tester is easy to use, reasonably priced, includes free firmware upgrades, and data management software.

    Measurement functions

    Vibration mode – Compares Vibration Levels against ISO 10816-3 standard (severity grades). Vibration meter measures overall level of vibration acceleration, velocity and displacement and FFT spectrum, route or off-route measurements.

    Tachometer – analyser measures speed of rotation by means of contactless optical sensor. The measurement result is displayed in RPM and Hz.

    IR thermometer – contactless measurement of object temperature. The measurement result is displayed in °C and °F.

    The 107VF Vibration tester kit includes:

    • 107VF display unit
    • AC102-1A accelerometer, incl. cable 1.5m, magnet for curved surface mount
    • Optical probe, magnetic stand (-T, -T2 only)
    • USB wall charger
    • USB cable
    • CD with ConSpect software and User’s Manual
    • Carry case
    Weight 1 kg

    Specifications

    Inputs – IEPE or charge type accelerometers, switchable. Optical RPM transducer

    AD conversion – 24 bits

    Frequency range – 1…10000 Hz

    FFT spectrum resolution – 400, 800, 1600, 3200 lines

    Measurement modes – vibration acceleration, velocity, displacement overall level and FFT spectrum. Route or off-route measurements

    Data storage – 4GB micro SD card

    PC interface – USB

    Display – color, sunlight readable

    Battery – LiPo rechargeable, up to 8 hrs continuous operation

    Dimensions – 128 x 70 x 35 mm
